Original FWD Atto 3 replacement parts
BYD Atto 3 Body, Lighting & Door Equipment
Match Atto 3 collision and closure parts to the original body version, side and equipment.
Identify the complete body design
Photograph the front, rear and relevant panel before separating a repair order. Do not carry original bumper or lamp references into an EVO request merely because the overall SUV shape is familiar.
Separate panels from complete assemblies
A bumper cover excludes many grilles, brackets and sensor holders unless explicitly listed. Likewise, a bare door or tailgate shell does not include glass, locks, wiring or lift assistance. State each supplied component and finish condition so two quotations cover comparable contents.
Match lighting and cameras by function
Record headlamp side and traffic-market approval, then identify control modules and connectors. Rear lamp sections have distinct mounting positions. Mirror and reversing cameras must match the installed display or surround-view system; a camera aperture or matching plug is not proof of compatibility.
Record the door and lift equipment
Window regulators need door position, glass-carrier and motor details, while latches and handles require locking and keyless-function records. Distinguish gas lift supports from powered tailgate spindles. Required initialization or calibration should be agreed with the qualified repairer before the order is approved.
Keep body protection outside the high-voltage enclosure
An underbody splash shield is not a traction-battery case, and an outer charge-port flap is not the charging socket. Identify damaged structures correctly before ordering ordinary body panels. For large shells, agree edge protection, reinforced packing and the dimensions needed for freight preparation.
Connected assembly checks
When repairing the front cooling-pack area, record the installed Ambient Temperature Sensor position before replacing the Front Lower Grille or Radiator Support; preserve its intended exposure to outside air.
Match the Headlights, Front Bumper and Front Lower Grille to the same original front-end design.
Record Tail Lights by lamp position and compare the Rear Bumper openings with the installed Parking Sensor holders.
Components to identify separately
| Assembly | Selection evidence |
|---|---|
| Headlights | Side, beam market, LED modules, connector and front-end version |
| Tail Lights | Left or right outer lamp, tailgate section, center bar and connector |
| Front Bumper | Original front-end version, parking openings, trim and mounting points |
| Rear Bumper | Facelift, parking sensor openings, reflectors and lower valance |
| Front Lower Grille | Lower intake aperture, insert dimensions, clips and bumper design |
| Side Mirror | Side, LHD or RHD, folding, heater, camera and connector |
| Fender | Side, body contour, wheel arch and fastening pattern |
| Hood | Original front body, hinge pattern, latch and reinforcement |
| Tailgate | Rear aperture, glass opening, latch and equipment contents |
| Door Shell | Front or rear, side, window frame and hinge and latch positions |
| Window Regulator | Door, side, glass carrier, cable routing and motor inclusion |
| Door Lock Actuator | Door or tailgate latch position, locking features and connector |
| Exterior Door Handle | Door, side, keyless electronics, lock barrel and connector |
| Tailgate Support Struts | Gas spring or powered spindle, side, length and end fittings |
| Wiper Motor & Linkage | Front linkage or rear motor, steering market and sweep geometry |
| Washer Pump | Front or rear wash circuit, outlet count, voltage and grommet |
| Washer Reservoir | Body shape, filler neck, pump seats and level-sensor contents |
| Fender Liner | Wheel position, arch profile, material and mounting holes |
| Underbody Shield | Front or rear location, panel outline, fixings and clearance |
| Radiator Support | Front carrier dimensions, lamp tabs, hood latch and cooling mounts |
| Charge Port Door | Outer body flap, hinge, latch and original body aperture |
| Parking Sensor | Bumper position, bracket angle, connector and control-system reference |
| Reversing Camera | Rear camera housing, field of view, plug and calibration compatibility |
Continue the parts list
Return to the Atto 3 system directory for other assemblies. Use the OE and VIN checklist for missing identification and the quotation guide for commercial and freight records.
