MG5 parts • petrol sedan, turbo and Electric estate identified separately
MG5 Cooling, Cabin & Low-Voltage Parts
Identify MG5 cooling, cabin and ordinary electrical parts by circuit. Separate petrol mechanical drives from estate low-voltage and controlled HV equipment.
Identify each fluid before comparing an exchanger
A radiator carries coolant, an A/C condenser or evaporator carries refrigerant, and an intercooler belongs to charge air. Identify actual circuits and joints before choosing from similar fins. An engine oil cooler and transmission exchanger also need different fluid records; body and gearbox labels alone cannot establish the accepted core.
Separate mechanical pumps from ordinary electric circulation
Retain engine drive, impeller, housing and seal details for petrol mechanical pumps. Electric estate low-voltage pumps need circuit labels, ports, brackets and electrical markings instead. A standalone pump or routing valve must not be represented as the complete high-voltage thermal module or traction-unit cooling assembly.
Restrict conventional compressor and heater requests
A belt-driven petrol A/C compressor needs pulley, refrigerant, mounting and control identification. A petrol cabin heater core belongs to its coolant-fed air-handler. Electric estate high-voltage compressors and heaters require separate supply capability and cannot be chosen from a pulley compressor or conventional heater-core picture.
Keep cabin airflow components with their actual case
The filter tray, blower wheel, speed controller and evaporator have separate fixing and electrical records. Retain LHD/RHD case identity and full module marking before agreeing complete or bare contents. A cooling fan is not a cabin blower, and a similar finned controller does not approve shared circuitry across sedan and estate platforms.
Distinguish ordinary loads from controlled electronics
A horn and window switch pack need their own voltage, socket and bracket or trim-seat record. They are not pedestrian-alert speakers, converters or body-control modules. Agree ordinary component contents without implying software, calibration or installation services, and keep high-voltage and safety modules outside the accepted mixed list.
Related assembly decisions
The cabin air filter seals its HVAC tray, the blower motor moves cabin air and the blower control module controls speed.
Identify the actual case and sockets before combining these separately supplied items.
The radiator cooling fan must align with the accepted radiator and A/C condenser stack.
Similar fins do not make coolant and refrigerant exchangers interchangeable; retain their separate pipe joints and mounting layers.
For an identified petrol loop, trace the water pump, thermostat / housing and coolant reservoir through the actual hoses.
An Electric estate loop needs independently identified ordinary circulation equipment rather than an engine-driven pump or thermostat reference.
Keep the coolant control valve, coolant temperature sensor and any ordinary electric water pump with their actual estate coolant circuit.
A warning message or a similar plastic housing cannot choose an integrated high-voltage thermal module.
Assemblies to identify separately
| Assembly | Application boundary | Selection record |
|---|---|---|
| Radiator | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Core, hose ports, gearbox cooler fittings and mounts |
| Radiator Cooling Fan | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Shroud, motor/controller, socket and mounting |
| Water Pump | Petrol mechanical pump or separately identified ordinary low-voltage estate pump; agree circuit, type and contents independently | Circuit, drive, housing, impeller and ports |
| Coolant Reservoir | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Bottle, cap rating, hose map, sensor and brackets |
| Thermostat / Housing | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Engine, opening requirement, housing, seals and hose map |
| A/C Compressor | Belt-driven petrol compressor only; high-voltage Electric estate compressor excluded | Installed drive, engine, pulley, refrigerant ports and control |
| A/C Condenser | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Core, connection blocks, receiver and mounting |
| A/C Evaporator | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Core outline, tube routing, block and seal faces |
| Blower Motor | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Wheel depth, rotation, flange and socket |
| Blower Control Module | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Label, heat sink, sockets and mounting |
| A/C Pressure Sensor | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Marking, thread/port, socket and signal function |
| Heater Core | Confirmed petrol cabin coolant heater core only; HV estate heaters and battery plates excluded | HVAC case, coolant tubes, core and seals |
| Engine Oil Cooler | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Actual engine oil circuit, exchanger/housing, coolant ports and seals |
| Coolant Control Valve | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Actual low-voltage valve, port routing, actuator, connector and circuit label |
| Coolant Temperature Sensor | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Coolant-loop position, sensing range, seat, seal and electrical signal |
| Horn Assembly | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Low-voltage horn, tone, connector, bracket and installed position |
| Power Window Switch | Exact sedan or Electric estate assembly and interfaces; a shared MG5 name does not establish interchange | Door, side, switch panel, connector, one-touch and lockout functions |
Continue the identified order
Use the MG5 system directory for other assemblies and the parts-list quotation guide for quantities and destination. Keep body and powertrain identification with every accepted item.
Auto parts inquiry
Send the vehicle and part evidence.
Include brand, full model, year, engine or EV drivetrain, OE/material code, quantity, destination and packing request. You can attach a list or old-part photos.
