Chery Arrizo sedans • Numbered models and powertrains kept separate
Arrizo Engine & Gearbox Service Parts
Divide an Arrizo service list into engine intake, cabin ventilation, lubrication, fuel supply and gearbox filtration.
Separate the service positions first
Keep the numbered model, original engine or transmission label and each housing photograph with its element. The 5e has cabin filtration but no combustion-engine intake or oil-filter requirement; a shared service-kit description should not hide those differences.
Compare the filter seat rather than capacity alone
For the intake element, compare perimeter, depth and sealing lip against the closed air box. For lubrication, distinguish threaded spin-on and cartridge arrangements, sealing face and accepted valve characteristics. A catalogue number listed for selected Arrizo 5/6 engines does not approve the oil-filter position of every 3, 7, 8 or hybrid variant.
Identify the actual gearbox service element
Documented Arrizo applications include manual, CVT, wet DCT and dedicated hybrid drives. A CVT description or a simulated ratio count cannot select one service filter. Establish whether the requested filter is serviceable, its pickup and seal format, and the gearbox marking. A transmission element must not be presented as an engine oil filter.
Keep plugs and coils with the installed ignition system
Preserve thread, reach, seat and accepted heat-range information for spark plugs, and socket, fixing and boot dimensions for coils. Turbocharging does not prove one injection or ignition layout. A combustion-engine hybrid still needs its own engine record; a battery-electric 5e does not acquire plugs or coils from its ordinary 5 relative.
Identify timing drive independently of the accessory belt
The documented Ecuadorian ordinary Arrizo 5 example has chain timing. Other engine labels need their actual chain or belt architecture confirmed. Itemize guides, tensioners and sprockets or belt contents separately. The accessory belt follows its fitted pulley route, and a 48V belt starter-generator arrangement cannot be assumed to use a conventional petrol accessory set.
Restrict conventional clutch kits to manual builds
A manual clutch inquiry needs the actual gearbox, disc spline, diameter, pressure plate, flywheel and release arrangement. CVT, wet DCT and dedicated hybrid internal clutch equipment are not alternatives selected from that kit. Preserve the accepted kit contents and vehicle record for repeat wholesale orders rather than treating every Arrizo transmission as one stock line.
Connected assembly comparisons
Keep the engine air filter intake housing separate from the cabin tray used by the cabin air filter.
A combustion-engine lubrication request needs its own engine oil filter seat and marking; cabin filtration on a 5e does not imply either engine service item.
Confirm whether the fuel filter is a separately serviced element or part of the tank delivery arrangement before discussing the fuel pump / tank module.
The transmission filter belongs to the identified gearbox service position, not that fuel circuit or an engine oil-filter position.
Match spark plugs to the installed combustion engine and compare the socket and boot length of the ignition coil separately.
A camshaft position sensor inquiry needs its own mounting depth and signal interface; an ignition symptom alone does not select a replacement.
Assemblies to identify separately
| Assembly | Application boundary | Selection record |
|---|---|---|
| Engine Air Filter | Identified combustion-engine or gearbox application; 5e BEV excluded | Engine code, air-box perimeter, depth and sealing lip |
| Cabin Air Filter | Exact numbered Arrizo, installed equipment and assembly identity | Tray dimensions, airflow direction, frame and media |
| Engine Oil Filter | Identified combustion-engine or gearbox application; 5e BEV excluded | Engine code, cartridge/spin-on format, dimensions and seal |
| Fuel Filter | Identified combustion-engine or gearbox application; 5e BEV excluded | Installed location, marking, hose ports and flow direction |
| Transmission Filter | Identified combustion-engine or gearbox application; 5e BEV excluded | Gearbox label, filter position, pickup and mounting |
| Spark Plugs | Identified combustion-engine or gearbox application; 5e BEV excluded | Engine marking, thread, reach, seat and heat range |
| Ignition Coil | Identified combustion-engine or gearbox application; 5e BEV excluded | Full label, socket key, fixing and boot reach |
| Accessory Drive Belt | Identified combustion-engine or gearbox application; 5e BEV excluded | Engine, complete belt code, rib count and route |
| Belt Tensioner | Identified combustion-engine or gearbox application; 5e BEV excluded | Engine bracket, pulley line, width, arm travel and mounting |
| Engine Timing Kit | Confirmed engine timing architecture; chain/belt contents identified separately | Engine label, actual chain/belt drive, guides, tensioner and accepted kit contents |
| Manual Clutch Kit | Only an identified manual gearbox; AT, CVT, DCT and hybrid drive excluded | Engine/MT code, disc spline, flywheel, cover and release system |
Continue the accepted parts list
Keep the full numbered vehicle and component record with the Arrizo grouped parts directory. The parts-list quotation guide covers quantity, destination and commercial fields without inferring price or stock.
