Chery Arrizo sedans • Numbered models and powertrains kept separate
Arrizo Brakes, Rear Suspension & Steering Selection
The documented Arrizo 3 rear drums require shoes, drums and wheel cylinders rather than a rear disc-caliper kit.
Record the axle and brake construction
Documented ordinary 5, Brazilian 6 Pro Hybrid and Egyptian petrol 8 examples have disc-brake arrangements. Identify the actual corner, friction outline, rotor or drum dimensions and installed markings before building an axle set.
Separate parking-brake mechanisms
A cable-operated parking brake and a motor-on-caliper EPB have different replacement boundaries. Confirm the actuator socket, screw interface and caliper revision on equipped 6 Pro or 8 builds. Do not add an EPB motor to a manual parking-brake vehicle, and do not infer a common rear friction set simply because two cars both have EPB.
Distinguish beam axles from multi-link carriers
Documented ordinary 3 and 5 examples use a rear torsion beam, while the Egyptian petrol 8 example uses multi-link suspension. A bare beam, separate rear carrier and individual arms have different pivot and wheel-end interfaces. Photograph the complete installed rear layout before comparing suspension pieces; a semi-independent description alone does not identify every carrier or bush.
Identify hydraulic assistance versus EPS
Egyptian Arrizo 5 MT and CVT documentation distinguishes hydraulic steering and EPS. A hydraulic pump request needs its fluid circuit, pulley and pressure interface. EPS has no hydraulic pump; rack assistance, electrical sockets and LHD/RHD remain separate selection fields. A common 5 name cannot select those systems interchangeably.
Retain wheel-end and sensor contents
A hub, bearing, knuckle and complete CV axle are distinct assembly boundaries. Keep spline, mounting face, ABS encoder and driveshaft end geometry with the exact wheel corner. A shaft support-bearing reference does not identify a complete axle, and a radio TPMS sensor is not the same component as a wired wheel-speed sensor.
Agree complete and partial suspension orders
Specify whether the order is for a bare damper, assembled strut, top mount, coil spring, arm with joints and bushes, or an individual replaceable joint. Spring seats, axle loads and fixing interfaces remain build-specific. Safety inspection and repair procedures should be handled by qualified technicians; purchasing an assembly does not diagnose the source of a vehicle symptom.
Connected assembly comparisons
Compare the backing outline of the brake pads with the installed caliper and the measured brake discs.
A brake caliper order must state carrier and parking mechanism contents; the documented Arrizo 3 rear-drum layout is a different assembly request.
Identify the brake master cylinder bore and hydraulic outlets independently of the brake booster assistance and mounting.
A corner brake hose needs its own end threads, bracket and length; agreeing these purchasing boundaries does not diagnose a braking fault.
A wired ABS wheel speed sensor reads wheel rotation, whereas the TPMS sensor monitors tyre pressure only on equipped builds.
The parking brake actuator is a separate EPB motor request and must not be added to a cable-operated parking-brake system.
Assemblies to identify separately
| Assembly | Application boundary | Selection record |
|---|---|---|
| Brake Pads | Exact numbered Arrizo, installed equipment and assembly identity | Axle, backing plate, caliper, shims and friction grade |
| Brake Discs | Exact numbered Arrizo, installed equipment and assembly identity | Diameter, thickness, hat height, centre bore and venting |
| Brake Caliper | Actual disc-brake corner, carrier and parking mechanism | Casting, carrier, piston, fluid port and actuator interface |
| Brake Master Cylinder | Exact numbered Arrizo, installed equipment and assembly identity | Cylinder label, bore, ports, mounting and reservoir seat |
| Brake Booster | Exact numbered Arrizo, installed equipment and assembly identity | Assist type, label, stud spacing and pushrod interface |
| Brake Hose | Exact numbered Arrizo, installed equipment and assembly identity | Union threads, fitting angles, brackets and routed length |
| ABS Wheel Speed Sensor | Exact numbered Arrizo, installed equipment and assembly identity | Corner, full marking, socket, lead route and pickup depth |
| TPMS Sensor | Only an installed radio pressure-monitoring system; absent grades excluded | Sensor label, frequency, protocol, valve and wheel seat |
| Parking Brake Actuator | Identified motor-on-caliper EPB only; cable parking brakes have no such motor | Caliper label, output drive, socket and fastening |
| Shock Absorber / Strut | Exact numbered Arrizo, installed equipment and assembly identity | Side, mounting, spring seat, stroke and load specification |
| Strut Mount | Exact numbered Arrizo, installed equipment and assembly identity | Stud pattern, central sleeve, bearing and spring seat |
| Coil Spring | Exact numbered Arrizo, installed equipment and assembly identity | Spring marking, ends, dimensions and vehicle load record |
| Control Arm | Exact numbered Arrizo, installed equipment and assembly identity | Axle/side, mounting centres, bushes and joint contents |
| Ball Joint | Exact numbered Arrizo, installed equipment and assembly identity | Arm retention, stud taper, mounting and fixing |
| Tie Rod End | Exact numbered Arrizo, installed equipment and assembly identity | Rack marking, thread, offset, adjustment and taper |
| Stabilizer Link | Exact numbered Arrizo, installed equipment and assembly identity | Joint-centre length, stud angle and motion clearance |
| Wheel Hub / Bearing | Exact numbered Arrizo, installed equipment and assembly identity | Flange, bearing contents, spline and ABS encoder |
| CV Axle / Drive Shaft | Exact numbered Arrizo, installed equipment and assembly identity | Side, spline, working length, joints and seal land |
| Steering Rack | Exact numbered Arrizo, installed equipment and assembly identity | Rack label, mounting, ratio, joints and interfaces |
| Engine Mount | Identified combustion-engine support only; not a BEV traction-motor mount | Engine label, bracket, position and mount design |
| Transmission Mount | Exact numbered Arrizo, installed equipment and assembly identity | Gearbox label, body pickups, bracket and isolator |
| Subframe | Actual front or confirmed rear carrier; battery structural protection excluded | Axle, build, suspension pickups and drivetrain interfaces |
| Steering Knuckle | Exact numbered Arrizo, installed equipment and assembly identity | Corner, bearing format, strut, arm and brake mounts |
| Brake Shoes | Documented Arrizo 3 rear-drum layout; other drums require their own vehicle evidence | Shoe outline, drum inside diameter, width and parking lever |
| Brake Drums | Confirmed rear-drum corner only; not the disc-brake arrangements of documented 5/6/8 examples | Inside diameter, accepted wear limit, depth, bore and hub format |
| Brake Wheel Cylinder | Rear-drum hydraulic cylinder only; a disc caliper is a different assembly | Bore, mounting, piston ends, pipe thread and bleed-screw position |
| Power Steering Pump | Confirmed hydraulic steering only; EPS has no hydraulic pump | Hydraulic label, pulley, bracket, fluid ports and pressure interface |
| Rear Axle / Torsion Beam | Only a confirmed rear torsion-beam installation | Body pivots, spring cups, damper pickups and wheel-end brackets |
Continue the accepted parts list
Keep the full numbered vehicle and component record with the Arrizo grouped parts directory. The parts-list quotation guide covers quantity, destination and commercial fields without inferring price or stock.
