Hyundai Accent Brake, Suspension and Steering Parts Guide
Use installed geometry, brake package and position to keep chassis orders precise.
Record the complete corner
State axle, side, brake package, wheel or hub format and parking-brake arrangement.
Separate regional chassis packages
Market-specific trims may use different brakes, springs, dampers, hubs and stabilizer hardware; confirm installed dimensions and labels.
Define assembly boundaries
Arms, hubs, struts and calipers may be bare or include bushes, bearings, brackets, motors or hardware.
Brakes & Parking Brake
Inspect front and rear hardware independently; Accent, Verna and Solaris applications can use rear drum or rear disc arrangements.
| Component | Selection boundary |
|---|---|
For Accent brake pads, start with axle, trim and caliper package; use backing-plate outline and dimensions and hardware, shim and wear-indicator scope to separate similar variants. | |
Specify Accent brake discs by front or rear disc package. Retain diameter, thickness and overall height and bolt pattern and hub offset so offers describe the same assembly. | |
Build an Accent brake shoes inquiry around rear drum service-brake application, then compare shoe arc, width and lever arrangement and springs and adjuster contents. | |
Match the Accent brake drums to rear drum application and trim. Record working diameter and overall height together with hub and bearing relationship before sampling. | |
For Accent brake caliper, start with axle, side and piston format; use bracket centers and disc width and hose and parking mechanism to separate similar variants. | |
Specify Accent brake master cylinder by brake-assist system and bore. Retain port locations and threads and reservoir and sensor contents so offers describe the same assembly. | |
Build an Accent brake booster inquiry around assist architecture, then compare stud pattern and rod arrangement and vacuum or control interfaces. | |
Match the Accent brake hose to axle, side and suspension. Record fitting type and threads together with length and retaining brackets before sampling. | |
For Accent abs wheel speed sensor, start with axle and sensor position; use tone ring or encoder type and lead length and connector to separate similar variants. | |
Specify Accent parking brake cable by body, wheelbase and cable section. Retain actuation mechanism and length, ends and brackets so offers describe the same assembly. |
Suspension, Steering & Mounting
Match axle, side, chassis and steering system before comparing dampers, joints, hubs, shafts, mounts or subframes.
| Component | Selection boundary |
|---|---|
Build an Accent shock absorber inquiry around front strut or rear damper position, then compare generation, trim and suspension package and spring seat and mounting geometry. | |
Match the Accent strut mount to front strut design and side. Record stud pattern and bearing format together with rubber isolator and supplied pieces before sampling. | |
For Accent coil spring, start with axle, trim and body load; use free height, wire and end shape and spring identification marks to separate similar variants. | |
Specify Accent control arm by independent-suspension position. Retain side and mounting geometry and bush and joint inclusion so offers describe the same assembly. | |
Build an Accent ball joint inquiry around axle, upper/lower position and side, then compare taper and retention method and separate joint or arm inclusion. | |
Match the Accent tie rod end to steering system and position. Record thread size and handedness together with taper and joint orientation before sampling. | |
For Accent stabilizer link, start with axle and roll-control layout; use link centers and end type and side and bracket orientation to separate similar variants. | |
Specify Accent sway bar bushing by front or rear stabilizer position. Retain bar diameter and bracket profile and bushing split, material and supplied pieces so offers describe the same assembly. | |
Build an Accent wheel hub / bearing inquiry around axle and hub or pressed-bearing format, then compare abs encoder and wheel studs and spline, flange and mounting dimensions. | |
Match the Accent cv axle to axle, side and drivetrain. Record inner flange or spline together with compressed length and outer spline before sampling. | |
For Accent steering rack, start with lhd/rhd and assist system; use mounting, input shaft and ratio and electrical connector or hydraulic ports to separate similar variants. | |
Specify Accent engine mount by engine code and mount position. Retain bracket and stud pattern and mount construction and controls so offers describe the same assembly. | |
Build an Accent transmission mount inquiry around gearbox and transfer-case code, then compare crossmember and stud pattern and insulator and bracket inclusion. | |
Match the Accent front subframe / crossmember to generation and drivetrain. Record steering-rack and control-arm mounts together with bare frame or bush and bracket contents before sampling. |
Continue with the same vehicle details
Use the Accent parts directory to identify other assemblies. Once specifications are clear, retain quantities, packing and destination through the shipping and quotation guide.
